Anti Stripping Fire Resistant refractory Chamotte brick Anti-Stripping fire clay brick for Glass furnace

Basic Information
Place of Origin: China
Brand Name: LUMING
Certification: ISO9001, Patents,Work safety standardization certificate
Model Number: KN
Minimum Order Quantity: 5 metric tons
Packaging Details: Standard Export Wooden Pallet
Delivery Time: Custom products 5-45 days
Payment Terms: L/C, T/T, Western Union,
Supply Ability: Annual Production Exceeding 120,000 Metric Tons of All Types of Refractory Materials Including Castables, Preforms, and Bric
Detail Information
Name: Anti-Stripping Fire Clay Brick Shape: Precast Block Or Brick
Bulk Density: ≥2.3g/cm3 Compressive Strength: ≥50Mpa At 1100℃×3h
Characteristic: Perfect High Hardness,high Refractoriness,high Anti-abrasive Application: Glass Furnace, Ladle, Pure Steel Furnace, Non-ferrous Metal Smelting Furnace And So On.
Highlight:

anti stripping fire refractory bricks

,

anti stripping low porosity fire clay bricks


Product Description



Low porosity fire clay brick

It is made of high quality hard clay,which which is formed by high pressure and sintered at high temperature.It has the characteristics of low porosity, high erosion resistance, high refractoriness under load,etc.It is normally used in the middle and lower part of the regenerator.

Item



Anti-Stripping fire clay brick

KN
Al2O3, ≥% 44
Fe2O3, ≤% 1.6
Bulk Density, ≥g/cm³ 2.3
Apparent Porosity ,≤% 18
Compressive strength, ≥Mpa 50
0.2Mpa Refractoriness under load, ≥℃ 1450
Linear Variation on reheating,1400℃x 2h,% +0~0.3



Size:
Common shape:
230X114X75,230X114X65,230x114x32mm,230x114x40mm,230x1114x50mm,
300X400X75mm
Special shape:
Side arch 230x114x75/70
Side arch 230x114x75/65
End wedge 230x114x75/70
End wedge 230x114x75/65
As per customers’ request and drawings to manufacture.



Contact us:0086-18905335290

Anti Stripping Fire Resistant refractory Chamotte brick Anti-Stripping fire clay brick for Glass furnace 0

Anti Stripping Fire Resistant refractory Chamotte brick Anti-Stripping fire clay brick for Glass furnace 1Anti Stripping Fire Resistant refractory Chamotte brick Anti-Stripping fire clay brick for Glass furnace 2

Anti Stripping Fire Resistant refractory Chamotte brick Anti-Stripping fire clay brick for Glass furnace 3Anti Stripping Fire Resistant refractory Chamotte brick Anti-Stripping fire clay brick for Glass furnace 4

Anti Stripping Fire Resistant refractory Chamotte brick Anti-Stripping fire clay brick for Glass furnace 5Anti Stripping Fire Resistant refractory Chamotte brick Anti-Stripping fire clay brick for Glass furnace 6Anti Stripping Fire Resistant refractory Chamotte brick Anti-Stripping fire clay brick for Glass furnace 7Anti Stripping Fire Resistant refractory Chamotte brick Anti-Stripping fire clay brick for Glass furnace 8Anti Stripping Fire Resistant refractory Chamotte brick Anti-Stripping fire clay brick for Glass furnace 9Anti Stripping Fire Resistant refractory Chamotte brick Anti-Stripping fire clay brick for Glass furnace 10





Characteristic:

Low porosity

Good thermal stability

Perfect molten Slag corrosion resistance
Excellent glass liquid corrosion resistance
High temperature performance

High temperature abrasion resistance
High Refractoriness under load

High Hardness
Excellent chemical stability
High Temperature Resistance and Perfect Thermal Shock Resistance
Excellent Corrosion resistance
High Strength
High Refractoriness
Excellent Chemical Corrosion Resistance
High Compressive Strength
Low Thermal Expansivity




Application:
Iron and steel industry,
non-ferrous metals,
building materials industry,
glass industry,
petrochemical industry,
electric power industry
machinery manufacturing industry

pellet, lime, calcined dolomite, ferroalloy, lithium salt, chemical and other rotary kilns



Packaging and shipping:

1. Strong packing will protect the goods from any possible damage during transit.
2. Solid packing and overall stuffing can prevent the cases from vibration and jarring.
3. We must take necessary precaution that the packing can protect goods from pilferage or rain.
4. We can confirm that we take every possible precaution to ensure that our products reach our customers all over the world in prime conditon.

1. Carton packaging +Pallet
2. tray + plastic film + fixed band .
3. pallets: 1*1m,0.93*0.93m .
4. tray weight: 1.6~2.0ton.
5. packaging according to customer service requirement

Anti Stripping Fire Resistant refractory Chamotte brick Anti-Stripping fire clay brick for Glass furnace 11

Anti Stripping Fire Resistant refractory Chamotte brick Anti-Stripping fire clay brick for Glass furnace 12

Our service:

1. when you inquire our product or price, we will reply you within 8 hours.

2. Well-trained and experienced technician answer all your questions in fluent English.

3. We provide the best after sales service. All our products have 1 year warranty period.

4. Offering the support to solve the problem in the selling or application period.

5. Competitive prices based on superior quality.

6. Guarantee samples quality same as your ordering production quality.

7. Development approaches:Scientific and technological innovation as the guide,Based on stable quality,high-quality service as the constant,Faith-oriented business integrity.

8. We believe "customer is God, quality is our unchangeable commitment".

9.Create and Win and Share Together

10.Let all kilns use the "heart" of energy saving and longevity


Anti Stripping Fire Resistant refractory Chamotte brick Anti-Stripping fire clay brick for Glass furnace 13

Anti Stripping Fire Resistant refractory Chamotte brick Anti-Stripping fire clay brick for Glass furnace 14Anti Stripping Fire Resistant refractory Chamotte brick Anti-Stripping fire clay brick for Glass furnace 15

Anti Stripping Fire Resistant refractory Chamotte brick Anti-Stripping fire clay brick for Glass furnace 16
